work_wpe44_processor

อุปกรณ์ปรับแต่งเสียง WORK WPE44 Digital Audio Processor

WORK PRO

อุปกรณ์ปรับแต่งสัญญาณเสียง WORK WPE44 Digital audio processor, 4 inputs + 4 outputs, Low pass, High pass, Low Shelving, High Shelving, Band pass, Peak, Notch and All pass, Ethernet control via WokCad 3 software or OSC commands

15,700 ฿

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม
หมวดหมู่: ป้ายกำกับ: Brand:

คำอธิบาย

WORK WPE44 Digital Audio Processor 4in/4Out

อุปกรณ์ปรับแต่งสัญญาณเสียง WORK WPE44 Digital audio processor, 4 inputs + 4 outputs, Low pass, High pass, Low Shelving, High Shelving, Band pass, Peak, Notch and All pass, Ethernet control via WokCad 3 software or OSC commands

WORK PRO WPE 44 is a 4 input, 4 output digital audio signal processor with external control capability. Its design and compact format make it perfect for use by audiovisual integrators and fixed installations.

The device has balanced inputs and outputs with 3-contact Euroblock connectors to provide them with greater immunity against electromagnetic interference.

The external control of this device is carried out thanks to its Ethernet connectivity, which can be done through the dedicated WorkCAD3 software or through OSC commands by third-party devices.

Features:

  • 4 In / 4 Out
  • Control software WorkCad 3
  • Control via OSC commands

Specifications

udio input 4 balanced (Euroblock 3 pins)
Processing per input channel 4 filters, Gain, Mute, Reverse polarity
Input Sensitvity 14 dBu (balanced) (3.88 Vrms)
Audio Output 4 balanced (Euroblock 3 pins)
Output channel processing 15 filters, 2 crossover filters (High pass, Low Pass), Input sum weighted matrix, Delay up to 8.19 ms, Compressor / Limiter / Noise Gate
Output sensitivity +10 dBu (balanced) (2.45 Vrms)
S/N ratio > 100 dB
THD+N < 0.01 %
Bandwidth 20 Hz – 24000 Hz
Sampling frecuency 48000 Hz
Filter types Low pass, High pass, Low Shelving, High Shelving, Band pass, Peak, Notch and All pass
No. Memories 8
Control protocols OSC over UDP and RUDP
Network Ports UDP 9000 / RUDP 9002
Ethernet 100 base TX
Includded accessories Wings for flat surface installation
Compatible accessories BL AR 19 (4 device in 1 rack unit installation accessory)
Power supply 24 Vdc / 500 mA (Source not included), PoE Class 0 802.3af
Consumption 3.6 W
Dimensions 109 x 133.7 x 40.45 mm
Weight 360 g

Downloads

ดาวน์โหลด All Docs WORK WPE44
