ลำโพงติดเพดาน Australian Monitor QF80CS Ceiling Speaker 8″

AUSTRALIAN MONITOR

ลำโพงติดฝ้าเพดาน Australian Monitor QF80CS เป็นลำโพงแบบ Back Box สามารถรองรับการใช้งานได้ทั้งแบบ Low impedance 16 Ohm และ 70/100 V line ขนาดดอกลำโพง 8 inch & 20mm coaxial high powered driver, QuickFit white frameless powder coated steel grill

12,500 ฿

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม
หมวดหมู่: ป้ายกำกับ:

คำอธิบาย

Australian Monitor QF80CS Back Can Ceiling Speaker 8″ 80W

ลำโพงติดฝ้าเพดาน Australian Monitor QF80CS เป็นลำโพงแบบ Back Box สามารถรองรับการใช้งานได้ทั้งแบบ Low impedance 16 Ohm และ 70/100 V line ขนาดดอกลำโพง 8 inch & 20mm coaxial high powered driver, QuickFit white frameless powder coated steel grill

When you need more power and solid bass response the QuickFit premium coaxial series of ceiling speakers are sure to exceed expectations. This premium series features two way coaxial drivers producing high SPL and detailed audio reproduction.

The frameless magnetic grills allows easy removal of the grill for tapping changes and quick installation. Porting through the front baffle improves bass response and ensures detailed bass definition. The sealed back-can provides isolation in the ceiling space ensuring spill in the ceiling cavity is kept to a minimum.

The QF80CS series of QuickFit ceiling speakers are the perfect choice for situations demanding high intelligibility and SPL. Pubs, clubs, bars, retail spaces, functions rooms, lecture rooms, boardrooms and many other commercial spaces requiring a premium high powered ceiling speaker solution.

Features:

  • 8 inch & 20mm coaxial high powered driver
  • QuickFit white frameless powder coated steel grill
  • Sealed steel back can
  • 20, 40, 80 watt taps @ 100V
  • 80 Watts @ 16 Ohms
  • Tile bridge included

Specifications

Form Factor Ceiling Max Continuous Power 80W
Tappings 80W-40W-20W-10W Max Program Power 160W
IP Rating No Max Peak Power 240W
EASE Model Yes SPL 1W/1m 90dB
Powered Passive Max SPL RMS 109dB
Driver Diameter 8″ & 20mm Max SPL Peak 115dB
Colour White Frequency Response (-3dB) 50Hz – 20kHz
Warranty 5 years Dispersion 110deg
Product Dimensions
(W x D x H)
308mm x 244mm Shipping Dimensions
(W x D x H)
348mm x 344mm x 270mm
Net Weight 5.65 Kg Shipping Weight 6.2 Kg

Downloads

ดาวน์โหลด Data Sheet QF80CS

ดาวน์โหลด Manual QF80CS
